SPECIFICATION
|
|
Line pull:5,897kgs/13,000lbs
|
|
Motor: 12V/6.0HP 24V/3.6HP
|
|
Gear Train: Three stage
|
|
Gear Ratio: 261:1
|
|
Freespooling Clutch: Rotating ring gear
|
|
Wire Rope Size: Φ3/8"×90'(Φ9.5mm×27.4m)
|
|
Wire Rope Type: Aircraft A7×19
|
|
Drum Size: Φ3.5"×8.1"(Φ89mm×206mm)
|
|
|
LINE PULL
|
|
Layer of Wire Rope
|
Max Line Pull
|
|
1
|
13,000lbs/5,897kgs
|
|
2
|
10,475lbs/4,752kgs
|
|
3
|
9,017lbs/4,091kgs
|
|
4
|
7,915lbs/3,590kgs
|
|
5
|
7,100lbs/3,220kgs
|
|
|
LINE SPEED AND AMP DRAW(1st layer of rope on the drum)
|
|
Load
|
Line Speed
|
AMP Draw(12V)
|
AMP Draw(24V)
|
|
No Load
|
24FPM/7.3MPM
|
55
|
49
|
|
6,000lbs/2,722kgs
|
6.6FPM/2.0MPM
|
210
|
172
|
|
10,000lbs/4,536kgs
|
4.0FPM/1.2MPM
|
290
|
260
|
|
13,000lbs/5,897kgs
|
2.6FPM/0.8MPM
|
350
|
310
|
|
|
|
|
DIMENSIONS(mm)
|
|
|
|
|
|
|
STANDARD ACCESSORIES
|
|
Controller TA-0906
|
|
Control Unit TA-0911
|
|
Mounting Hardware
|
|
Handsaver Strap
|
|
Wire Rope TA-0111
|
|
4 Way Roller Fairlead TA-0903
|
|
Hook TA-0402
|
|
|
|
PACKAGE
|
|
Winch weight : 62.5kgs/137.5lbs
|
|
Gross Weight : 70.1kgs/154.2lbs
|
|
Box Dimension : 710×255×450 mm(28"×10"×17.7")
|
